How to Find the Right Transistor Substitute

It’s hard to pick the right transistor replacement. Here’s what you need to know to pick the right one for your product.

How to Find the Right Transistor Substitute

Having largely adhered to Moore’s Law since the early 1970s, transistor counts on semiconductors have been multiplying for over half a century. Today’s most advanced chips—including microprocessors, memory chips, and graphics processing units (GPUs)—utilize tens or even hundreds of billions of transistors (some AI processing units contain several trillion). Because of the sheer number of these devices required to build modern ICs and their ubiquity across the electronics manufacturing landscape, component engineers are frequently tasked with the challenge of replacing transistors in their bills of materials (BOMs).

There are an array of relatively widespread scenarios, encompassing everything from component specifications to supply chain contingencies to nascent compliance obligations, that force engineers to undertake the process of identifying a transistor substitute. Perhaps the most prevalent of these scenarios occurs when an existing transistor gets an end-of-life (EOL) notice, informing users of impending obsolescence. Engineers may also need to seek out cross references if supply chain disruptions or other manufacturing changes affect the availability or lead time of a transistor.

Original equipment manufacturers (OEMs) themselves may also impose mandates on engineers that press them to search for a transistor substitute. These could include a directive to achieve price optimization in the marketplace, or upgrade specific performance measures like enhanced speed or lower power consumption. Under these circumstances, engineering teams are compelled to identify a transistor equivalent that not only fulfills all the criteria of its predecessor, but also introduces new value to the product or company. The breadth of reasons to find a viable transistor replacement makes the task a highly commonplace one for component engineers—a process inextricably woven into the work of maintaining BOMs, qualifying parts, and ensuring a manufacturer’s operational continuity.

Understanding Your Current Transistor

To effectively carry out the work of identifying a transistor substitute, engineers need to possess a comprehensive, multifaceted grasp of the transistor(s) currently represented in their BOMs. This should always start with the component’s parametric features. These include—but are not limited to—temperature range, including maximum and minimum operating temperatures; total power dissipation; current gain; and various voltage-related parameters.

Another notable parametric feature individuals should be aware of is configuration. Generally speaking, there are three primary transistor configurations: common base, common collector, and common emitter. It’s critical for the transistor equivalent to have the same configuration as the component it’s replacing in the BOM. Finally, engineers need to know the specific type of transistor they’re selecting a replacement for. There are two main types: bipolar junction transistors (BJTs) and field-effect transistors (FETs). These categories are further delineated by subcategories. While BJTs are typically categorized as either NPN or PNP transistors, FETs have a more complex taxonomy that begins with junction field-effect transistors (JFETs) and metal oxide semiconductor field effect transistors (MOSFETs).

In addition to the parametric specifications, component engineers and their teams must also be thoroughly versed in the outgoing transistor’s package features. This is often referred to as the transistor outline, or TO. As a starting point, engineers should understand the transistor’s packaging material—typically plastic, metal, or a combination of the two—and the package type (examples include TO-66, TO-72, and TO-92). There are, however, numerous other packaging features that need to be carefully matched to the component being replaced.

  • Pinout: A “pinout” refers to the three leads, or legs, present on all transistors: the base, the collector, and the emitter. Transistor substitutes must match the specific pinout of the component they’re replacing to ensure that the rest of the BOM and the product’s overall design will not be compromised or require major, time-intensive overhauls.
  • Lead Shape. The shape of the leads can vary from one transistor to the next, and engineers want to be sure transistor equivalents match the predecessor’s specifications as closely as possible.
  • Mounting Type. In general, the mounting type refers to whether the transistor is through-hole or surface mount. Through-hole transistors are fitted into drilled holes on printed circuit boards (PCBs). Surface-mounted technology, which rose to prominence in the 1980s, enables transistors to be mounted onto the surface of the PCB via soldering. While surface-mounting has become the vastly more popular technology, there are still plenty of transistors that utilize through-hole mounting.

The final category of criteria to be aware of when carrying out transistor replacements is qualification level. Transistors are typically qualified as either industrial, automotive, or military, based on features like durability, longevity, and capacity to function effectively in extreme environments. Any transistor substitute should be the same grade as the component it’s superseding.

Choosing a Transistor Replacement: The Distributor Website Method

Under most circumstances, component engineers have two options when embarking on a search for a transistor equivalent. In the first option, they look for a viable replacement themselves, using distributor websites like Digikey or Mouser Electronics. Professionals who utilize this method need to compile the various parametric and packaging features for the transistor they’re looking to replace. It’s worth highlighting that this represents a distinct endeavor unto itself, one that may require considerable time and, depending the engineer’s experience level, additional resources. Once those specifications have been collected, the next step is to actually go into one or more of these websites in search of a replacement that matches the extensive criteria and can be seamlessly slotted into the BOM.

While using these websites are usually free, the process comes with a few notable drawbacks. First, it requires a great deal of legwork on the part of the engineer, who must manage a substantial amount of complex information and possess the expertise and discernment to recognize the difference between negligible parametric differences and those that disqualify a potential transistor replacement. Additionally, these websites don’t have access to all the components on the global electronics supply chain, which means that individuals won’t see all the available crosses. (In addition to these websites, on rare occasions the supplier will include a cross-references page with a list of suggested transistor equivalents, usually arranged by part number. This is, however, an edge case, and certainly not something engineers should rely on when developing a recurring, repeatable transistor replacement strategy.)

Choosing a Transistor Replacement: The Component Database Method

The second technique companies can avail themselves of when looking for a transistor equivalent is employing a component database solution. The best component database software allows engineering teams to search for replacement parts in a highly efficient fashion that reduces the pressure on individuals to navigate thickets of specifications and make consequential decisions based on minute differences. Instead of wielding large clusters of parametric and packaging specs, these database platforms let individuals simply use the part number to search for crosses that are close parametric matches and meet form-fit-function (FFF) requirements. These platforms don’t have the same limited scopes as distributor websites, either, and give users access to the entirety of the billion or so electronic parts currently available worldwide.

Component database software also goes beyond the technical specifications by providing comprehensive, up-to-date data on pricing, availability, and lead time. Having immediate and reliable access to this information can be critical for teams working with fixed budgets and within tight timeframes, allowing them to rule out parts that are too expensive or don’t fit into product delivery dates. Further, incorporating this type of market data helps engineers narrow down their list of component candidates, accelerating a process that can sometimes get bogged down by an excess of options.

Taken as a whole, these tools reduce bottlenecks and minimize the opportunities for human error by giving engineers faster, more accurate access to an abundance of actionable component information. The result, in many cases, is a streamlining of the entire transistor replacement process.

There is no shortage of scenarios that force component engineers to replace an existing component with a transistor equivalent. It’s a frequent, recurring challenge all but guaranteed to persist in a highly globalized supply chain subject to the annual spate of EOL notices, a burgeoning regulatory landscape, and the unceasing stream of localized disruptions that spontaneously impact availability and lead time.

Having a systematic, codified procedure for choosing a transistor substitute can give manufacturers a valuable buffer when it comes to maintaining production timelines in the midst of unforeseeable supply chain developments. And while component databases can, technically, serve as part of this institutionalized procedure, they also feature unavoidable blindspots and onerous data requirements that can lead to uninformed decision-making and operational slowdowns—limitations that supply chain risk management software consistently transcends.
